UHF 4-Channel Wireless Microphone RH860U

Model

RH860U

Frequency Range

UHF640-840MHz

Stability

<±20PPM

Dynamic Range

>95dB

T.H.D

<0.5dB

Frequency Response

50Hz-18KHz

Audio Output

0-300mV

Receiver

Power Requirement

DC15-18V

Power Consumption

5W

S/N

>98dB

Image Rejection

>85dB

ACI

>85dB

Sensitivity

>5dBu(SINAD=20dB)

Measurement

480x210x43mm

Microphone

Modulation

FM

Frequency Deviation

±40KHz

Power Requirement

1.5Vx2
